5600 CFM late Camaro SS BRUSHLESS Radiator Fan: 50% and Full Power.
Автор: dbarton
Загружено: 2023-07-10
Просмотров: 3361
Video made to accompany high-output cooling fan testing info in my page: https://www.240turbo.com/BrushlessFan...
This fan was tested in free air.
12.7v (static): 10% duty cycle (full power). 5300 CFM (2600 RPM). 50 amps.
These next tests below are on this video (except for RPM and max-CFM tested earlier). The below tests were done with the engine running to achieve full voltage.
14.5v: 50% duty cycle. 3300-3400 CFM. 13.6-13.9 amps.
14.5v: 10% duty cycle (full power), 5690 CFM (2800 RPM). 48-53 amps.
The low 13 amp draw at 50% (3300 CFM) is very impressive. It should be noted the full power test pulled the battery voltage down from 14.4v at (50%) to 13.7v. So you really SHOULD NOT run this fan at full power for your AC or for any reason that I can think of, except maybe a trip to the sun.
For a video of a full power test: • Full power test. 2019 Camaro SS BRUSHLESS ...
CFM testing was done using an Aiomest AN-846A anemometer. Same one used by Fast Monty's Garage in this video: • How to measure the CFM of your Electric Fan. . The same fan area calculation methods were used.
