Time Crisis GUN4IR light gun mod in less than 1hr
Автор: Gustav Wingburen
Загружено: 2023-06-06
Просмотров: 18809
GUN4IR®
The Ultimate 4 Points Lightgun System
http://forum.arcadecontrols.com/index...
This is my GUN4IR conversion of a Time Crisis 1/2/3 arcade light gun.
I did the video as reference for myself, hence the sometimes poor footage, but I tried to insert text to explain what goes where if anyone tries to follow.
I also did a quick basic setup in a picture which might be easier to have as somthing of a reference here https://ibb.co/FgNPK2M
Not shown in the video is the making of...
GX16-6pin and inserted it in the L-bracket dremeled for tight fit
MOSFET PCB setup, used for the motor - solenoid components PCB by Prozac4545 ( https://oshpark.com/shared_projects/b... )
IR LEDs (SFH-4547 4x points x group of 3)
The MOSFET could also be used to control the solenoid but I use the D4184 MOSFET control module board as it uses optoisolation which truly separates the USB GND from the power supply GND
The lens used in this video is a 198° fish-eye lens (Apexel) but 180° fish-eye would be almost identical to this
