How to Install a Load Resistor for LED Lights (The Theory, Wiring Diagrams, etc)

If you need parts, try...

LED Load Resistors (USA) - https://ebay.us/m8PKfz
LED Load Resistors (UK) - https://ebay.us/uRD203
LED Load Resistors (AUS) - https://ebay.us/YeosZM
LED Load Resistors (CAN) - https://ebay.us/aWuyx7
LED Light Bulbs (USA) - https://ebay.us/DH49Bw
LED Light Bulbs (UK) - https://ebay.us/s0HTyv
LED Light Bulbs (AUS) - https://ebay.us/b1CLo1
LED Light Bulbs (CAN) - https://ebay.us/ykllmS

Disclosure: The links above are 'affiliate links' This means we may garner a small commission (at no cost to you) if you choose to make a purchase. Thanks for your support... 😃

For more information, see:

https://do-it-up.com/vehicles/wiring/...

Replacing a filament light bulb with an LED light bulb, can sometimes cause the vehicles electronics (or turn signal relay) to flash the turn signals faster than normal (hyper flash). The CAN bus system (vehicles electronics) can also think there is a bulb failure.

Installing load resistors will mimic the filament light bulbs load on the system. The turn signals will flash at the correct speed, and the CANbus system should also thinks the light bulb load is correct and not report any errors.

To add a load resistor to a turn signal (indicator) it has to be wired into each LED light bulb in parallel. I.e. The load resistor goes across the light bulb connections, between the supply and ground.

A load resistor is required for each LED light bulb in the turn signal circuit, (you may only want to upgrade the rear of the vehicle? In which case you only need 2 x load resistors).

Load resistors can generate lots of heat, so position carefully.
