So I bought a new 2024 Bobcat T770 back in July of last year and ran it for 220 hours and decided to trade it in on a new 2025 T 86 gold package. I recently demoed a 2023 model T 86 from Bobcat WhiteStar my local dealer and really liked the machine much more than the T770. Moving into an R series after having 2 M series machines this machine actually felt like it was new, going to a different cab and machine style. so far I’ve put about 20 hours on this machine and it has been awesome so much more power even though its only 13 more horsepower. I’ll be hitting some of the features of the gold package on this T 86 and will be taking a look under the cab at all the different changes between the M and r series. #constructionequipment #2025 #4mranch #bobcatequipment #bobcat #t86 #onetoughanimal #youtube #subscribe #viralvideo T86 Key Specifications
T86
Rated Operating Capacity (ISO)
3,800

lb
Operating Weight
12393

lb
Ground Pressure (Rubber)
4.8

psi
Auxiliary Std Flow
23.6

gal/min
Auxiliary High Flow
36.6

gal/min
Joystick Control
Standard

Engine
T86
Emissions Tier (EPA)
Tier 4

Engine Cooling
Liquid

Engine Fuel
Diesel

Horsepower
105

hp
Turbocharged Engine
yes

Performance
T86
Rated Operating Capacity (ISO)
3,800

lb
Rated Operating Capacity 200 lb. Counterweight
3,950

lb
Rated Operating Capacity 300 lb. Counterweight
4,025

lb
Rated Operating Capacity 400 lb. Counterweight
4,100

lb
Rated Operating Capacity with Torsion
3,700

lb
Operating Capacity (50% of Tip)
5429

lb
Tipping Load
10857

lb
Operating Weight
12393

lb
Travel Speed
5.5

mph
Travel Speed (2-speed option)
10.7

mph
Ground Pressure (Rubber)
4.8

psi
Capacities
T86
Fuel Tank
31.6

gal
Hydraulic System
T86
Hydraulic System Pressure (Standard and High Flow)
3,500

psi
Hydraulic System Pressure (Super Flow)
4,061

psi
Hydraulic Standard Flow
23.6

gal/min
Hydraulic High Flow (optional)
36.6

gal/min
Hydraulic Super Flow (optional)
42

gal/min
System Relief @ Quick Couplers
3,450

psi
Auxiliary Std Flow
23.6

gal/min
Auxiliary High Flow
36.6

gal/min
Dimension
T86
Length without Attachment
120.4

in
Width
78

in
Width (with bucket)
80

in
Height with Operator Cab
83.1

in
Height to Bucket Hinge Pin
132

in
Reach @ Maximum Height
38.4

in
Length of track on ground
66.3

in
Track Width
17.7

in
Track Width - Optional
17.7

in
Ground Pressure (Optional Tracks)
4.8

psi
Features
T86
5-Link Torsion Suspension Undercarriage
Optional

Radio Remote Control (SJC required)
Optional

Reversing Fan
Optional

Standard Display (includes keyless start)
Standard

Speed Management
Standard

Heated Cloth Air-Ride Seat
Standard

LED Front and Rear Lights
Standard

Joystick Control
Standard

Air Conditioning
Standard

Backup Alarm
Standard

BICS System (Interlock)
Standard

Suspension Seat
Not Applicable

Two Speed Travel
Standard

Auxiliary Hydraulics
Standard

Bob-Tach Attachment System
Standard

Power Bob-Tach
Standard

Ride Control
Optional

Horn
Standard

Sound Option
Standard

Dual-Direction Bucket Positioning
Standard
