Extracting Firmware from Linux Router using the U-Boot Bootloader and UART

In this video, we discuss how to extract firmware from a Linux Router using UART access to the device's bootloader. This device used U-Boot as the embedded system's bootloader which provides us with a way to extract flash memory contents using a few handy U-Boot commands. Then we use a small python script to convert the U-Boot hex dump to a binary file which we can analyze with binwalk.

video on finding UART:
   • Finding UART and Getting a Root Shell on a...

tool to convert u-boot hex dump output to a binary file:
https://github.com/nmatt0/firmwaretools

U-Boot command documentation:
https://u-boot.readthedocs.io/en/late...

IoT Hackers Hangout Community Discord Invite:
  / discord
