Lidar Scan to Revit from an iPhone?! (Polycam to Revit Workflow)

On this episode of BIM After Dark Live I will be walking you through the process of taking a lidar scan to Revit from an iPhone. That's right, laser scanning with your iPhone and then using that information in Revit. Using an app called "Polycam" I will give you my super simple Polycam to Revit workflow.

When I first bought an iPhone 12 I couldn't wait to see what I could do with the LIDAR capabilities. My search led me to an app called "Polycam". Fast forward to almost a year later and Polycam is a title sponsor of this livestream! Who would have thought? Well, I have continued to use their product over the last ten months and can't wait to show you the workflow I have developed.

I'll be talking about the steps it takes to get a LIDAR (and photogrammetry ) scan from Polycam on your iPhone or iPad into Revit, my lessons learned along the way, and a case study in which I surveyed and existing house with just Polycam and made a pretty darn good existing conditions model from it!

Sit back, relax, and let's geek out!

Links Mentioned:
Try Out Polycam Today - https://polycam.bimafterdark.com
Save 10% Off Enscape Today - https://enscape.bimafterdark.com
Join the BIM After Dark Community - https://community.bimafterdark.com
Episode 28 (Laser Scanning and Revit) w/Matt - http://therevitkid.blogspot.com/2020/...


Timestamps:
00:00 Introduction
04:20 Polycam (iPhone to BIM!)
04:47 Introducing the 5 Step iPhone LiDAR to Revit Process
13:55 Big "Bad" BIM Tip of the Week (Type In Dimension Formulas)
19:00 Step 1 - Capture Using iPhone or iPad
23:48 Step 2 - Export to PTS (Point Cloud Format)
26:36 Step 3 - Import into Autodesk Recap (and Save)
31:30 Step 4 - Import into Revit as a Recap Point Cloud
35:30 Step 5 - Scaling Your Point Cloud in Revit (Photo Mode Only
45:49 Case Study - Existing Conditions Scanning of a House
57:25 Bringing Your Polycam Scan into Twinmotion
01:01:27 Outro
