FSAE 03 Vehicle Control Unit - VCU (Podcast)

Automotive Powertrain Channel:
Engineering Technical Specifications for Formula Student Electric Powertrain System (FSAE / FSTaiwan)

This engineering specification outlines the EV-Powertrain architecture, a sophisticated control system designed to transition student racing teams from traditional mechanical builds to software-defined vehicles. The framework emphasizes predictive control and high-precision communication, specifically utilizing EtherCAT to achieve microsecond-level synchronization across four-wheel independent drives. By replacing standard PID controllers with Model Predictive Control (MPC), the system can simultaneously optimize vehicle handling and energy efficiency while respecting complex physical constraints like battery heat and tire grip. Ultimately, the document serves as a strategic roadmap for integrating dual-domain isolation and advanced real-time computing platforms to ensure Formula Student competitors achieve both elite performance and strict safety compliance.

------------------------------------------------------------------------------------------------------------------------
Core Subsystems and Functional Requirements:
1. Engineering Requirements Specification (SOR)
2. Powertrain Topology and High Voltage Architecture
3. Vehicle Control Unit - VCU
4. Electric Drive System - EDS
5. Motor Control Unit - MCU
6. Power Electronic System (covering DC-DC, OBC, PDU)
7. HV Accumulator System
8. Battery Management System – BMS
9. Energy Management System - EMS
10. Thermal Management System - TMS
11. HV Safety (Covering TSAL、IMD, HVIL, MSD, Fuse, Contactor, HV Wiring Harness & Connector)
12. Functional Safety
13. Cybersecurity
14. V-Model Development Roadmap
15. System Integration and Verification
