TIA Portal PLC Tutorial | PID Controllers with S7-1200 – PI & PID Implementation | L 41

💙In this video, learn how to implement and test PID controllers in TIA Portal with an S7-1200 PLC. TIA Portal PLC Tutorial, PID Controllers with S7-1200 – PI & PID Implementation. We explain why proportional controllers alone have steady-state errors, then introduce PI and full PID control. The tutorial covers setting up PID instructions in TIA, tuning parameters, and testing with both PLCSIM and a real PLC. Practical tank level control examples demonstrate how PID maintains the liquid level at the setpoint.
💚💚
✅ Chapter Sections:
0:00 – Introduction: PID Controllers in TIA Portal
0:40 – Proportional Controller Review and Steady-State Error
1:30 – Why Proportional Controllers Cannot Eliminate Error
2:20 – Introduction to PI and PID Controllers
3:10 – How PI Controller Compensates Proportional Weakness
4:00 – Role of Derivative Term in PID Controllers
4:50 – Effect of PID Coefficients on Controller Performance
5:30 – Designing a PID Controller in TIA Portal
6:10 – Using Cyclic Organization Block for PID Execution
6:50 – Configuring PID Instruction Inputs and Outputs
7:30 – Setting Process Type, Measurement Units, and Output Direction
8:10 – Testing PI Controller in Simulation
8:50 – Using PLCsim 1500 and Factory IO for Accurate Testing
9:40 – Activating PID Controller via HMI and PLC
10:20 – Controlling Water Level with PID: Automatic Mode Example
11:00 – Tuning PID Coefficients in TIA Portal
11:40 – Testing Tuned PID Controller with S7-1200 PLC and HMI
12:20 – Adjusting Setpoint and Observing PID Performance
13:00 – Summary and Practical Tips for PID Implementation
