TIG Welding Tungsten Sharpener Build

A scenic stroll through the build of a useful tool for any TIG welder.

Gas Tungsten Arc Welding (GTAW) or TIG Welding works best with a carefully prepared tungsten electrode. A dedicated diamond tungsten grinder is the best way to get a perfectly prepped TIG tungsten electrode angle. Most of these grinders are expensive, so this DIY diamond tungsten sharpener is a must have for the shop.

***Affordable self-paced welding courses taught by me***
https://courses.timwelds.com

TIG Welding Basics (Full Tutorial):    • TIG Welding Basics for Beginners
Subscribe to TimWelds: https://www.youtube.com/timwelds?sub_...

Parts used in this build:
****Online Order****
Diamond Grinding Wheel: https://amzn.to/3pi5JlM
****Good ol' Harbor Freight****
Harbor Freight "Drill Master" Angle Grinder
****Leftovers in the Shop****
1.5" Steel Angle, .25" Thick, .5" Long
3/4" Square Tubing for base
2" Steel Angle for Base
****Hardware Store****
1/4-20 Bolt, .5" Long
5/8" Machine bushing, 14 Gauge Thickness
U bolt for hold down
Adhesive Rubber Feet
Cheap Spray Paint
