Eico 1030 High Voltage Supply Restoration
Автор: Jamzoni
Загружено: 2020-02-06
Просмотров: 1517
The Eico 1030 High Voltage Power Supply is very similar to the Heathkit Models IP-32 and IP-17. I prefer the Eico since it has more options for filament voltages and the main rectifier circuit is a simple full-wave configuration rather than a voltage doubler providing for more output current. The Eico is designed to deliver 150 milliamps at 400 VDC for the main B+ and 2 milliamps at -150 VDC bias Voltage. The filament voltages can be 6.3 VAC with up to 6 Amps, 12.6 VAC at 3 Amps and even a center tap of the 6.3 VAC supply. One word of caution, dealing with these high voltage supplies exposes the user to majorly lethal voltages that can kill or cause serious harm.
