Evaluating SOLIDWORKS Surface Quality
Автор: Hawk Ridge Systems
Загружено: 2020-10-26
Просмотров: 6101
Surface quality is extremely important for SOLIDWORKS experts and beginners alike, especially in consumer product design.
In this tutorial, we provide an overview of several different techniques to eliminate the guesswork when assessing surface quality and avoid errors/warnings.
These techniques include visual inspection with RealView appearances, Deviation Analysis, Surface Curvature Combs, Curvature colors, and Zebra Stripes.
0:00 - Intro
1:04 - Visual Inspection
2:37 - Deviation Analysis
4:06 - Surface Curvature Combs
5:32 - Curvature Colors
6:23 - Zebra Stripes
7:50 - Recap Interpreting Tangent Versus Curvature Continuous: • SOLIDWORKS Interpreting Tangent vs Curvatu...
For more information on SOLIDWORKS: https://hawkridgesys.com/solidworks
Technical Support Knowledgebase: https://support.hawkridgesys.com/
