How to Install Extended Wheel Studs & Spacers on a NSX (FULL DIY)

Learn how to install extended studs and wheel spacers on your 91-05 Acura/Honda NSX. I went with ARP M12 x 1.5 Honda Studs with a 2.85" length. As for the spacers, I went with trusted brand from Germany, H&R. These effectively converted the Mugen M7 wheels on my rear axle from 17x9 +46 to 17x9 +26. They're perfectly flush now and I'm loving it.

The hardest part of this install would be removing the axle nut that is torqued to 242 ft*lbs (you need a 36mm socket and either a large breaker bar 1/2" or 3/4" drive at minimum or a HD impact gun). After that, you need an angle grinder to grind down the wheel bearing assembly as shown in the video--if you don't have that you'd most likely have to resort to the alternative method of removing/installing studs, which is to grind down 1/4 of the head. A bench sander or a Dremel would have be used in this case.

Lastly, the Lisle wheel stud installer is the last special tool needed for this job. Feel free to drop me a comment if you have any questions.

Parts Required:

ARP Extended Studs (Pack of 5) P/N: 100-7712: https://amzn.to/48gtwYn

Optional parts:
Spacers of your choice (Front hub bore is 70.1 and rear bore is 64.1)
Open Ended Lug nuts of your choice (M12 x 1.5)


Special Tools Required:

Lisle 22800 Wheel Stud Installer: https://amzn.to/49yoxn3
36mm Socket: https://amzn.to/49BuEH1
Angle Grinder: https://amzn.to/4bBRUXd
Hammer: https://amzn.to/49yoCqR

0:00 - Introduction
2:36 - Removing the ABS Sensor
2:52 - Hammering the Studs Out
3:10 - Removing the Axle Nut
3:19 - Removing the Hub
4:15 - Explanation of Grinding the Hub
6:23 - Lisle Stud Installation Tool
6:59 - Installing the Extended Wheel Studs
9:23 - Torquing the Axle Nut to 242 ft*lbs
9:38 - Installing the Spacers
10:51 - Finished Photos
