How to Create Perfect V-Carve Inlays on your CNC
Автор: Carbide 3D
Загружено: 2024-07-01
Просмотров: 69332
We've made some updates to Carbide Create (the basic version!) to enable you to create flawless V-carve inlays with ease. In this video, we'll walk you through how to use the new Inlay workflow with a Fallout-Inspired coaster.
To try it out for yourself, download the latest version Carbide Create at: https://carbide3d.com/carbidecreate/d...
Speeds and Feeds Used in Example:
1/8" Endmill
RPM: 24,000
Feed Rate: 55 IPM (1400 mm/min)
Plunge Rate: 24 IPM (600 mm/min)
Stepdown: 0.06" (1.5 mm)
Stepover: 0.06" (1.5 mm)
60 Degree V-Bit
RPM: 24,000
Feed Rate: 39 IPM (1000 mm/min)
Plunge Rate: 16 IPM (400 mm/min)
Stepdown: 0.10" (2.5 mm)
Stepover: 0.006" (0.15 mm)
If you have any feedback about the new Inlay workflow, you can chime in here:
https://community.carbide3d.com/t/inl...
Chapters:
0:00 Intro
0:51 Tools & Materials Used
1:35 Coaster Body Design
5:06 Inlay Plug Design
9:32 Machining the Coaster
11:14 Machining the Inlay Plug
11:55 Assembly of Inlay & Cleanup
15:36 Finished Coaster
