How to Remove Automatic Transmission on 3rd Gen C3 Corvette

This video shows you how to remove an automatic transmission on a third generation C3 Chevrolet Corvette, model years 1967-1982. This is a relatively straightforward procedure, but it is important to follow the steps carefully to avoid damaging the transmission or other components.

Chapters:

00:00 Intro
00:14 Remove the starter
05:28 Remove converter dust shield
06:37 Remove torque converter from flex plate
10:58 Remove Shift Linkage
13:33 Remove speed odometer cable
14:08 Remove cross member and parking brake cable
30:40 Remove kick down cable and fluid
41:10 Remove bell housing bolts
47:05 Dropping the transmission from the car
49:25 Outro

Tools and supplies needed:

1. Wrench set
2. Socket set
3. Jack stands
4. Transmission jack
5. Drain pan

Instructions:

1. Park the car on a level surface and set the parking brake.
2. Place the car in Park and turn off the engine.
3. Disconnect the negative battery cable.
4. Raise the front end of the car and support it on jack stands.
5. Place the transmission jack under the transmission and raise it slightly.
6. Drain the transmission fluid into the drain pan.
7. Disconnect the transmission fluid cooler lines.
8. Disconnect the electrical connector from the transmission.
9. Disconnect the shifter cable from the transmission.
10. Remove the bellhousing bolts and remove the bellhousing.
11. Carefully remove the transmission from the car.

To install the new transmission, simply reverse the steps above. Be sure to use a new gasket and filter, and to fill the transmission with new fluid.

Here are some additional tips for removing and installing an automatic transmission on a third gen C3 Corvette:

Be careful not to overtighten the bellhousing bolts.
Make sure that the transmission is properly aligned before installing the bellhousing.
Use a torque wrench to tighten the bellhousing bolts to the proper specifications.
Fill the transmission with new fluid and check for leaks before starting the engine.

If you have any questions or concerns about removing or installing an automatic transmission on a third gen C3 Corvette, please consult a qualified mechanic.

Safety:

Always wear safety glasses and gloves when working on your car.
Be careful not to burn yourself on the hot transmission fluid.
Use a transmission jack to support the transmission when removing and installing it.

Disclaimer:

This video is for informational purposes only. We do not recommend that you attempt to remove or install an automatic transmission on your own unless you have the necessary skills and experience. If you are unsure about how to proceed, please consult a qualified mechanic.
