[SGeC] 74LS14 Hex Schmitt-Trigger Inverter Gates with Totem-pole Output
Автор: Saigon eCircuit
Загружено: 2024-08-12
Просмотров: 373
Описание:
74LS14 Hex Schmitt-Trigger Inverters with Totem-pole Output
A hex inverter with Schmitt trigger refers to a digital logic component that combines six individual inverters with Schmitt trigger inputs into a single package. The Schmitt trigger input allows for improved noise immunity and hysteresis in the input signal, providing more robust and reliable signal processing.
This device contains six independent gates each of which performs the logic INVERT function. Each input has hysteresis which increases the noise immunity and transforms a slowly changing input signal to a fast changing, jitter free output.
![[SGeC] 74LS14 Hex Schmitt-Trigger Inverter Gates with Totem-pole Output](https://imager.clipsaver.ru/27LJkGehlis/max.jpg)
