Fusion 360 2D Drawing Tutorial | Its semi-automatic!

This Fusion 360 2D drawing tutorial shows you the basics of setting up a page with orthogonal and pictorial views scaled for your page. We also add centre marks, dimensions and notes.
WATCH NEXT: How to use this channel    • Channel Welcome | How to learn Fusion 360
Buy Me a Coffee https://buymeacoffee.com/arnoldrowntree
Patreon   / arnoldteaching

There is a difference between part and assembly drawings. There are many other conventions and traditions that have grown up with the topic during its one hundred year history but this is a good place to begin. The paperless office is not here yet and neither is the paperless design office. If you have CNC equipment you can sometimes bypass the printer but you'll need to print off paper drawings if you work with other people and if you're anything like me its good to have a paper plan in your hand when you go out to the garage to make something. We'll make a part drawing here, assembly drawings will have to wait for another video.

If you haven't done the 16 Basic Tutorials you should start at the beginning:- Beginners Tutorial #1 of 16    • Learn Fusion 360 in a few hours. Part 1

See:- The Intermediate Playlist    • Intermediate Fusion 360 Tutorials
