PENGUIN - 48 Carrier Single Deck Heavy Duty Wire Braider

Penguin braiding machines are built with design and material perfected over years of experience in building a range of braiding machines & are engineered for precision braiding of high performance high pressure hoses. The modular design makes it possible to tailor the machine to suit the requirement of the customer.
These Braiding machines are characterized by high productivity, simplicity and excellence in performance. The hoses manufactured by these machines are far superior to conventional hoses in strength, appearance and durability.
Penguin Braiding Machines are indigenously designed and Penguin is the only indigenous manufacturers of the heavy duty machines in India and one among the very few quality manufacturers in the world.

• 100% carriers and bobbins included in the machine price and supplied along with machine
• Built-in Haul-off with separate geared motors for each jaw suitable for flexible and rigid hoses
• Latest Technology – No top plate braider
• Heavy duty horn gears for high pressure braiding – Tension from 10 to 14.5 kg / carrier
• Acoustic enclosure
• Sufficient suction fans for temperature control
• Large bobbin capacity upto 9 kg wire / bobbin and 1.25 kg yarn / bobbin – Reduced bobbin change time
• Carriers require minimum compensation
• Heavy duty deck plates
• Ergonomically designed doors and openings
• Smooth carrier transfer by “carrying type” horn gears
• Specially crafted heavy duty horn gear and smooth track
• All springs included in the supply of carriers; Clutch springs & Torsion springs
• Hose guides at each braiding point and Haul-off ends
• Suitable for braiding – High tensile brass coated steel wire, Stainless steel wire, Different yarns like Kevlar, Aramid, Nylon, Polyester (Coated and Uncoated)
• 48 carrier braiders for maximum coverage upto 75mm braiding diameter
• Electronic gearing for "On the Go" pitch control
• Independent deck drive motor and control
• Complete Electronic drives, controls, PLC, Touch panel and Pitch control
• Start / Stop / Jog push buttons at convenient places
• Soft Start / Stop system
• Single wire cut, Bobbin empty, Full wire cut sensors included for efficient quality braiding
• Interlock switches for door openings
• Top indication lights for operator convenience
• Preform pin for “No flare” hose
