200 AMP Mast Service Upgrade | Surge Protection & Generator Wiring

In this video you’ll see how an existing electrical service is upgraded from 100 amps to 200 amps and gets an updated grounding system and whole-house surge protection. Home portable generator interlock and transfer switch installation too!

Permits and Inspections are required for this work. Check with your local building department and utility company before doing anything you see in this video. Electrical work is not a hobby.


200 AMP Mast Service Upgrade Materials List:

Arlington MK200WH 2” Mast Kit
Reliance PB30 Power Inlet Box
Champion 125/ 250 VOLT L14-30 Locking Generator Cord
Eaton Cutler-Hammer BR 200 Main Breaker Plug-On Neutral 40/ 80 circuit panel
Eaton Generator Interlock Kit BRMIKCSR 150A-200A Indoor
2” x 4” Galvanized Nipple
JCPL 200 amp OH meter enclosure
2” Bonding Bushing
2” Locknuts & Plastic Bushings
2” x 10’ Threaded Galvanized Electrical Conduit
Water Ground Clamps
Galvanized 5/8” x 8’ Ground Rods plus clamps
15 amp single pole circuit breakers
20 amp single pole circuit breakers
30 amp double pole circuit breaker
60 amp double pole circuit breaker
Eaton Plug-On Whole House Surge Protective Device
4/0 Aluminum Conductor
#2 AWG Aluminum Conductor
#6 AWG Copper Conductor
Arlington Bonding Bridge
4/- AL butt splices
2” Rubber Splicing Tape
1” Black Vinyl Tape
1” White Vinyl Tape
