PART 8 | Control Siemens G120C Drive with PLC 1200 & HMI | Full Setup and Parameter Overview
Автор: Mahan Negar Afzar
Загружено: 2026-01-05
Просмотров: 46
In this video, we demonstrate how to control a Siemens SINAMICS G120C 1.1 kW drive using a Siemens S7-1200 PLC (CPU 1215C) and an HMI. Before running and setting the application, the complete control structure is explained step by step for better understanding.
In this video you will learn:
Speed control of the G120C drive via PLC
Monitoring drive parameters: actual speed, motor current, DC link voltage, and drive status
Hardware overview:
Siemens S7-1200 PLC (CPU 1215C)
KTP700 Basic HMI
SINAMICS G120C 1.1 kW, Profinet, without UHF filter
Profinet network configuration and IP addressing
Drive commissioning using the TIA Portal wizard
Selecting operating modes (Profile mode & Fieldbus mode)
Standard telegram selection and data exchange between PLC and drive
Handling ramp parameters inside the drive
Online parameter configuration and testing
This video is suitable for automation engineers, technicians, and students who want a practical and structured guide to controlling Siemens G120C drives with PLC and HMI.
