Singer 201-2 Rewire - Part 2a Rewiring the motor
Автор: Bob Fowler
Загружено: 2020-09-14
Просмотров: 24475
In this series, we cover the complete rewiring of a vintage Singer 201-2 sewing machine. In Part 1, we covered the removal of the motor, light, and switch assembly. In part 2 (a) we show you, in detail, how to disassemble the motor, how to clean it, and add new connecting wires to the field coils. Also in Part 2 (b), we will disassemble the lighting unit, and clean and rewire it. The single wire at the switch will also be replaced. Part 3 will show how to reattach everything to the sewing machine, with special care showing how to feed the wires from the light through the machine so they don't interfere with the mechanism.
In the video, I misspoke... It's NOT 5/16" wicking material for the grease wicks, it's 3/16". Sorry...
Consumables used from McMaster-Carr:
Item 8767K226 Firm Felt Cord F1 3/16" diameter (grease wick for motor)
Item 9600K33 SBR Rubber Grommet for 7/16" hole diameter and 3/32": material thickness.
Item 7113K551 Ring Terminals, non-insulated for 22-18 Wire Gauge and number 8 screw.
Item 7856K43 Heat-shrink tubing 0.13" ID before shrinking.
