Chris demonstrates syncing Whelen Split Vertex Super-LED Hide-Aways

http://sirennet.com/whvtx609x.html A Single, Self-Contained, Hemispheric Hide-A-Way Light
The Vertex Super-LED Hide-A-Way Light is an ultra small, self-contained, hemispheric LED light, for surface mount or internal mount within composite head lamps, cornering lamps and tail light assemblies. This self-contained unit uses an in-line combination lamp driver/flasher which means a simple installation with no separate lamp drivers, flashers, ballast or power supplies to install. New lens technology enhances light distribution for optimum dispersion and intensity of the warning signal at critical angles. Includes pre-wired and sealed 8 foot neoprene cable to the lighthead and lamp driver, with 4-22 gauge power, pattern and synchronize pigtail wires. Only 7/8" in height, this small hemispheric LED lighthead is perfect for most applications where size and intensity are critically important.

This IS the Split Version of the Vertex. Now available in a Red/Blue Split, Red/White Split, and Blue/White Split.

Features:

Each light module contains 6 - Gen3 Super-LEDs.
25 Scan-Lock flash patterns.
Includes synchronize feature for alternating and synchronous flashing of multiple lamps.
Aluminum base and advanced thermal heat management system is designed for endless years of trouble free service.
Pre-wired and sealed 8 foot neoprene cable to the lighthead and lamp driver, with 4-22 gauge power, pattern and synchronize pigtail wires.
Lamp and in-line lamp driver are fully encapsulated for moisture and vibration resistance.
Omni-directional lighthead mounts in any position (orientation), vertically or horizontally.
Available in Red/Blue Split, Red/White Split, and Blue/White Split.
SAE Class 5.
No RFI noise emitted.
Voltage: 10 - 16 VDC.
Amp draw: .750/peak and .300/average.
1" hole makes this LED module backwards compatible with all standard 1" Hide-A-Way style lamps.
Two screws hold the lamp securely in place.


Whelen 5 Year Warranty

NOTE: The Split Version of the Vertex must be installed behind a clear lens or mounted using the flanges.

Vertex Hide-A-Way Light assemblies are sold individually.
Price shown is for ONE (1) Vertex Lighthead.
This product is NOT sold in pairs.
