1980-1986 Ford Truck Instrument Cluster Refurbish with Tach Add, LED Bulbs, and Gauge Testing

This video demonstrates the process use when I do a tachometer addition to a 1980-86 Ford Truck Instrument Cluster.

This process includes:
Disassembly
Gauge Testing
LED Bulb testing
And a Final Product

Notes:
-Please note that 4k (4,500 without yellow/red zones on right side) and 6k RPM tachs can be used for gas applications only! For diesel applications, a 4,500 (with yellow/red zones on right side) or 3,500 Tach must be used.
-As mentioned there will be some minute differences for the 1980 year. For this application you will need a 1980 circuit with a Tach circuit (engineering number E0TZ-10K843-B). This will be designated by a “E0TF-10C956-BB” part number on the printed circuit.
For the 1981-1986 printed circuits with the tachometer circuits, the numbers you need to know are engineering number E1TZ-10K843-B and part number E1TF-10C956-BA.
-A tachometer cannot be added using a factory warning light cluster (warning lights for the oil indicator and the ALT indicator). The only way a tachometer can be added is by making a custom housing and circuit.

Please do not hesitate to comment below with questions or… comments.
Also, please head over to www.Facebook.come/BJsClassicClusters to get ahold of me the fastest with inquiries or questions!

Thank you!
