Development of Lateral Surfaces of Solids Pentagonal Pyramid 01
Автор: Mechie's Study Circle
Загружено: 2024-06-25
Просмотров: 24556
Описание:
A regular pentagonal pyramid of side of base 35 mm and altitude 65 mm has its base on HP with a side of base perpendicular to VP. The pyramid is cut by a section plane which is perpendicular to the VP and is inclined at 30° to HP. The cutting plane meets the axis of the pyramid at a point 30mm below the vertex. Obtain the development of the remaining part of the pyramid
