More efficient Bedini SSG Charger | Bedini SHK v1.0 circuit (DIY)

I forgot to mention in the video, this circuit is not self starting! It sometimes does if you connect the power supply to the input of the bedini charger. You can trigger it by using a 1 kOhm resistor and connect it to the input "+" and base of the transistor, and then disconnect it again! You can also trigger it with a 240v light bulb. Don't use too little ohms to trigger it else you could damage the transistor!

Never use this charger with open circuit (will damage the transistor). And neon bulbs do not protect the transistor! Make always sure you have something connected to the output of the bedini charger! If you measure the output voltage of the bedini charger, always have a capacitor connected to the output of the bedini or a battery! If you drive a light bulb or a LED always use a capacitor in between! And please note the max ratings of the transistor! You can search for the datasheet on the internet! Just type in the name of the transistor. Do not charge capacitors beyond the max voltage of the transistor (will damage the transistor)! And use high voltage transistors for bedini chargers, like the PHE13007.

PROS of the SHK circuit compared to SSG:
*Diode 1 allows less leakage between the Base and Emitter of the transistor (transistor shuts off quicker, resulting more efficiency of the bedini charger)
*Much lower ohms can be used without losses in the output
*You get the full flyback current discharge from the coil.
*The transistor and resistor is less stressed
*Diode 1 protects the sensetive part of the transistor up to 1000v due to 1000v diode from the flyback current (wireless/induction current from the power winding)
*Ultra fast (UF) diodes were actually designed for this and are much more efficient than the 1N diodes

CONS of the SSG compared to SHK:
*Diode 1 let's some flyback current flow trough the resistor "wireless/induction current from the power coil" (causes losses, the lower the ohms of the resistor = more losses in the output), it also stresses the resistor heavily.
*Slow, low efficiency diodes 1N

SHK has no cons in comparison to SSG


Similar diodes:
UF4007 (1A)
UF107 (1A)
UF2007 (2A)
MUR4100E (4A)

If you ask me about my free energy tests, you should read the description of my other video "Brushless Kromrey Generator". But short to the SSG, although the SHK circuit is way more efficient and effective than the original Bedini SSG, I still wasn't able to pull any additional energy from the vacuum. Therefore I call that theory busted! Energy also cannot be "pulled", it's energy itself that makes motion possible, not the other way around!


Video Tags:
Bedini SSG, Bedini SHK, Bedini Motor, Battery desulfator, Battery refresher, diy, tinker
