RetroTINK-4K Super NES NTSC Optimal Timing Tutorial

Learn how to create an optimal profile for the Super NES on the RetroTINK-4K.

This tutorial pulls information from the RetroTINK-4K wiki. It is highly recommended that you visit the wiki to learn how to use the RT4K.
https://consolemods.org/wiki/AV:Retro...

This tutorial is not for the Analogue Super NT, MiSTER or other consoles as these all have very different processes for optimizing Super NES video.

This tutorial goes over how to make 3 different types of profiles:
1) Automatic Sample Detection for games that switch horizontal resolutions often.
2) Manually optimize for games that output 512x224.
3) Manually optimize for games that output 256x224.

Recommended Cables:
RGB SCART Sync-on-Luma
https://insurrectionindustries.com/pr...
https://www.retrogamingcables.co.uk/S...

RGB to YPbPr Component Cables
https://stoneagegamer.com/ypbpr-compo...
https://www.retrogamingcables.co.uk/S...

0:00 Intro and my hardware, and hardware compatibility
1:28 Creating a profile that does automatic sampling detection (256 vs 512)
14:53 Creating a profile for manually sampling Super NES "High Resolution" modes
18:51 Creating a profile for manually sampling Super NES normal resolution modes.
