DMX Arduino Chauvet FootC2 remote mod
Автор: Shane Easton
Загружено: 2019-10-09
Просмотров: 488
Modification to a Chauvet C2 Foot DMX controller by installing a arduino mini pro to cycle through scenes and chases. This uses midi note on commands to the midi input with chases and scene in a mixed order. Every time a single momentary switch is pressed the arduino sends the next Midi note on from 1 to 36 then back to one. Other components are a small power supply that rectifies, filters and regulates uo to 12v 1 am dc to 5 VDC for the arduino. A phone jack to mount into the Chauvet unit and a USB serial board to upload sketches as I am using a small arduino with no USB.
DMX_Schroll_v02.ino Arduino sketch in Google drive
https://drive.google.com/open?id=1EWd...
