FPV Long Range The ALPS | TBS CROSSFIRE (Armattan Chameleon)

My last long range journey to the dolomites flying with my FULL TBS Armattan Chameleon (view description). Please help me reach 1k subs (target achieved...thank you all!!!), share and subscribe now: http://bit.ly/davideFPVsub ...thanks!

-------------------------------
If you like what I do, please support me and make an offer here: https://www.paypal.me/dangeletti ...thanks!!!
-------------------------------

Mini quad used: setup 1
---------------------
Mini-quad setup 1:
Frame: Armattan Rooster 5''
Motors: Armattan Titan 2306 / 2450Kv
ESCs: 30A Armattan 2-6S (Dshot600)
FC: CL Racing F4S All-in-one flight controller with Betaflight OSD (Betaflight 3.3, Dynamic Filter, PT1, No gyro notch filters, anti turtle on)
VTX: AKK X2-ultimate [ 1200mw ]
FPV Cam: Runcam Swift 2 - 2.5mm

Mini-quad setup 2 (TBS):
Frame: Armattan Chameleon 5''
Motors: EMAX RS2306 2400KV
ESCs: 30A Armattan (Dshot600)
FC: Holybro Kakute AIO F4 V1 (Betaflight 3.4, Dynamic Filter, PT1, No gyro notch filters, anti turtle on, Gyro|PIDloop @ 32/8khz)
VTX: TBS UNIFY PRO V3
FPV Cam: Runcam Swift 2 - 2.1mm

Mini-quad setup 3:
Frame: Armattan Chameleon-Ti 5 inch
Motors: T-MOTORS F60 PRO II 2500kv
ESCs: DYS ARIA Blheli_32 35A ESC (Dshot1200)
FC:CL Racing F4S All-in-one flight controller with Betaflight OSD (Betaflight 3.4 RC5 Dynamic Filter, PT1, No gyro notch filters, anti turtle on, Gyro|PIDloop @ 8khz/8khz)
VTX: TBS UNIFY PRO V3
FPV Cam: Foxeer Predator V2 - 1.8 mm


Mini-quad setup 4:
Frame: Farins Frame GEKO 5''
Motors: T-Motor F40 PRO II 2400kv
Combo Kakute: FC F4 V2 + TEKKO 4in1 35a 1200 DShot
(Butterflight 3.5.0, kalman Filter, Dynamic Filter, PT1, No gyro notch filters, anti turtle on, Gyro|PIDloop @ 32/8khz, gyro_filter_q @ 400 and gyro_filter_r @ 88)
VTX: TBS UNIFY PRO V3
FPV Cam: Runcam Eagle Pro 2 - 2.1mm

TX: Frsky Taranis X9D SE Plus
RX: TBS Crossfire micro receiver V2 (Horizontal Polarization)
Action Cam: GoPro session 5
Props: HQProp 5x4.3x3 PC V1S AND Cyclone DALPROP T5045C
Battery: Tattu and Sectorbat (1300mah 4s 75c and 1550 4s 75c)
FPV Goggles: Fatshark Dominator V3 (LaForge V2 diversity module)
Antenna: TBS Triumph / Aomway set and ImmersionRC spiroNET 8 dbi

------------------------------------------
