Kadette 86X - Ballast Tube Replacement w/ a Rectifier Diode, Zener Diode & Power Resistors
Автор: RestoreOldRadios
Загружено: 2019-05-11
Просмотров: 2608
A quick look at the cabinet after stripping the old finish before reviewing the circuit changes I made to replace the defective Ballast Tube, 165R4. A 1N5408 Diode and 25W 35 Ohm Power Resistor is now being used to reduce the Tube Heater string voltages. In addition, the Type 40 Dial (Pilot) Lamp location was changed as well as adding a 40 Ohm 5W shunt Power Resistor and 6V Zener Diode to reduce the stress on the Dial Lamp during cold starts.
Supporting theory:
http://www.vintage-radio.com/repair-r...
http://williamhaywoodjones.blogspot.c...
Thanks for watching and subscribing to my channel on vintage radio repair.
The playlist for this series:
• Kadette 86X
