Intellivision Kiosk Multiplexer

Kiosk Multiplexer – The electronic brains behind the large kiosk displays used in stores to sell Mattel Electronics’s Intellivision games and consoles. This deep-dive video covers A LOT of material. Be sure the check out the links at the bottom for even more information.

Chapters:
1. 00:00 Intro
2. 00:43 What is it?
3. 03:57 Demos
4. 09:58 Intellivoice Games
5. 14:06 Other Games
6. 19:26 Reverse Engineering
7. 24:25 Sphinx of Quartz Judge My Black Vow
8. 26:44 Board Revisions: B vs D
9. 28:04 Miscellaneous
10. 30:29 Bugs
11. 31:41 Outro

Links:
Reverse Engineering documentation:
https://docs.google.com/document/d/1U...

Schematic and AtariAge discussion forum:
https://atariage.com/forums/topic/303...

“Intellivision Store Display” video by Trade-N-Games
   • Intellivision Store Display! Trade-N-Games...

“Mattel Intellivision Kiosk Demonstration” video by cylonrdr
   • Mattel Intellivision Kiosk Demonstration

Papa Intellivision:
Main site: https://papaintellivision.com
Document that briefly mentions POP hardware: https://papaintellivision.com/pdfs/CC...
