Fishing Lure Making | Part 1, Flat Sided Crankbait, Free Downloadable Template

Inspired by Pro Angler, Ott DeFoe, I make these Flat Sided Crankbaits. It is designed with front center of gravity and profile that allows swimming near bottom while hitting rocks and woods, to attract bites. Thin and flat sided Balsa wood gives it natural tighter wiggling action.

I have created 2 versions, “Fast Floating” (7g or 0.25oz) and “Slow Floating” (10.5g or 0.37oz). Fast Floating when I am fishing in shallow water with heavy cover of rocks. Higher buoyancy to get out of snag when pausing retrieve. Slow Floating when I need to cast further and getting to the bottom strike zone quickly.

During prototype testing, I was truly surprised by the effectiveness. 3 hits within minutes from shore on very pressured fishing ground, and without issue with snagging. Both versions work very well, I do notice that Slow Floating is more effective during low light condition, the knocks on the bottom are harder and it gives more time for the fish to react when retrieve pauses.

I painted the lure in 2 colors: “Pumpkin Seed” and “Hot Copper Green Shad”. The colors work well but do apply any color that suits your fishing condition.

I hope you enjoy making this lure and catching with them. As always, support the channel: “Like”, “Subscribe” and “Share”. Tight Lines!

There are 3 parts in Flat Sided Crankbait Making series,
Part 1:    • Fishing Lure Making | Part 1, Flat Sided C...
Part 2:    • Fishing Lure Making | Part 2, Flat Sided C...
Part 3:    • Fishing Lure Making | Part 3, Flat Sided C...

The template used for this lure is available to download at Google Drive link: https://drive.google.com/file/d/1f9mD...

-- Chapters --
00:00 - Lure action and catch
00:52 - Lure template
01:20 - Cutting and sanding to shape
03:21 - Sawing lip location on lure
04:30 - Marking hook hanger locations
05:07 - Making hook hangers from wire
07:00 - Steps to make “Fast Floating” version
10:24 - Steps to make “Slow Floating” version
16:50 - End of Part 1

-- Lure Specification --
“Fast Floating” Weight: 7g or 0.25oz
“Slow Floating” Weight: 10.5g or 0.37oz
Body Length: 55mm
Treble hook size: 8

-- Building Material --
Balsa Wood: 3/8” or about 10mm
Stainless steel wire: 0.9mm
“Fast Floating” Split Shot: 1.4g x2
“Slow Floating” Split Shot: 1.4g x4
Acrylic sheet: 1.5mm thickness
