LS-DYNA TUTORIAL 10: Three Point Bending of Sandwich Structure with EPS Foam as Core

Автор: Ameen Topa

Загружено: 2020-03-03

Просмотров: 35886

Описание:

This is a long and heavy tutorial, so buckle up everyone!

Topics covered in this video, includes but not limited to:
How to make a simple sandwich structure
How to set up three point bending test simulation
How to model failure with ADD_EROSION
How to model styrofoam with MAT063 CRUSHABLE_FOAM
How to prevent negative volume error in solid elements
How to combat hourglassing in soft materials
How to 'glue' parts with tienodes contact
How to use apply velocity/displacement with BOUNDARY PRESCRIBED MOTION RIGID
How to extract the forces with BNDOUT option

As mentioned, I did the modelling of
EPS foam for my final year project. Here the link to the published paper:
https://www.hindawi.com/journals/mse/...
(do check it out and hope you can cite if it is helping you in your own research!) 😁😁😁

Here is the link to the stress-strain file:
https://drive.google.com/open?id=1_1p...

Here is a sample of 3 point bending of foam:
https://drive.google.com/open?id=1Qbn...
