Razor Dune Buggy Wheel and Axle Upgrade
Автор: Epsilon Zero Karts
Загружено: 2022-05-15
Просмотров: 7329
In this video, I remove my previously modified stock axle and go for a 3/4" solution. Parts are still a little tough to come by, but there is a much better selection than the unique metric axle Razor put on. This is my first build-type video, so let me know what you think.
Here are the parts, minus some bolts, washers, and nuts to connect the pillow blocks and to recondition the front spindles:
From BMI Karts:
1x 400149 Custom Axle
Axle Diameter & Material: 3/4'' OD (Steel)
Axle Length is over 48: No
Length Overall Length in Inches: 28
Keyway Width: Standard
Keyway Length: Entire Length
Thread Size: Standard
Length of Threads: Standard
Step Down Axle: No
2x 400059 3/4" Axle Lock Nut (3/4-16)
2x AZ1064 5" Azusalite Wheel, 3.5" wide, 1" to 3/4" Step Live Axle (Rear)
2x AZ1061 5" Azusalite Wheel, 3-1/2" wide, 5/8" ID Bearing
4x AZ7037 4.10/3.50 Sawtooth Tire Rim Size: 5
4x AZ7132 4.10/3.50-5 Inner Tube
6x 400120K Steel Split Locking Collar (3/4" Bore)
10x AZ8442 3/16" x 3/16" x 1 1/4" Keystock
AZ2568 Steel Multi-Patterned Sprocket / Brake Hub (3/4" Bore) (Used as a brake rotor)
From Amazon/Ebay:
1x PGN - UCP204-12 Pillow Block Mounted Ball Bearing - 3/4" Bore - Solid Cast Iron Base - Self Aligning (2 Pack)
1x PGN - #25H Heavy Duty Roller Chain x 10 feet + 2 Free Connecting Links
3/4" to 1" Inch Sleeve Adapter w/Step Key
From Speedy Metals (to mount 5/8" bearings on spindles, but I welded up my own custom spindles later to add Ackerman steering):
5/8" OD {A} x 0.385" ID {B} x .120" Wall {C} DOM Steel Tube-24"
SKU: dom.625x.120-24
Cutting Tolerance: Plus or Minus 3/4"
I used a #24 25t sprocket from Redboar Chain. I have since swapped to #420 chain and deleted the jackshaft after replacing the motor, battery, and controller again.
