1996 - 2000 GM OBS 4WD K Truck Vortec V8 5.0L / 5.7L Oil Cooler Line Leak Repair (Chevy & GMC)

In this video we tackle an engine oil leak on the engine oil cooler lines on GM K truck (4WD) models (e.g., K1500, K2500, K3500) with the Vortec V8 engine (either 5.0L or 5.7L). Whether from Cadillac, Chevrolet, or GMC.

The vehicle illustrated is a 1998 Chevrolet Cheyenne K2500 with the 5.7L vortec engine, but the procedure, parts, and technique shown is applicable to any 1996 thru 2000 old body style (OBS) GM truck GMT400 type such as the Chevrolet Silverado, GMC Sierra, Chevrolet Suburban, Chevrolet Cheyenne, Chevrolet Tahoe, GMC Suburban, Cadillac Escalade, or GMC Yukon. The 1995 and earlier K trucks are very similar, but do not share the same retaining ring clip or cooler line design that were introduced in 1996.

Also applicable to some Holden branded GM K trucks in Australia of this same time period.

The eBay and Amazon search links below are paid links, for which I may be compensated and earn a commission, if you choose to buy the parts and tools shown in this video thru them:

GM 15112871 (supersedes GM 15996516) inlet oil cooler line: https://ebay.us/RdVXVg and on https://amzn.to/3CHewVi

GM 15724727 oil cooler line metal retaining ring clips: https://ebay.us/Qxum3t and on https://amzn.to/3u0CHdD

GM 15112870 (supersedes GM 15996517) outlet oil cooler line: https://ebay.us/AEMskz and on https://amzn.to/3CHGX5r

For the black plastic oil cooler line retaining clip GM 15725347: https://ebay.us/ZM6GB2

GM 12337820 plastic oil cooler lines zip tie: https://ebay.us/d4neXP

GM 463015 oil cooler line o-ring seal: https://ebay.us/EaN9Ku and on https://amzn.to/3JeYuV1

GM 15043741 oil cooler line connector fitting: https://ebay.us/mirqYi and on https://amzn.to/3R6F0Hg

Lisle 43890 fan clutch removal tool: https://ebay.us/EQg2Ht

And if I've saved you some $$ here, consider some coins for the coffee tip-jar! https://ko-fi.com/drshock

1996 1997 1998 1999 2000

Chapters:
0:00 - Problem overview
1:10 - Removing the upper & lower fan shroud
9:02 - Disconnecting the cooler lines from oil cooler
11:07 - Disconnecting the cooler lines from oil filter adapter
15:34 - Disconnecting the cooler line retaining bracket clip
16:26 - Removing the cooler lines from the truck
17:38 - GM service manual procedure tips
20:42 - Replacement GM part numbers
21:49 - Installing the cooler lines to oil cooler
25:36 - Installing the cooler lines to oil filter adapter
30:12 - Parts explosion diagram
30:41 - Torquing the oil cooler line fittings
31:36 - Re-installing the cooler line retaining bracket clip

#drshock #obstruck #obstrucks

Disclaimer: DrShock, the alias for the human content creator for this YouTube channel, is not responsible for any damages, injuries, losses, or liabilities associated with any repairs, upgrades, or maintenance performed on yours, or any other, vehicle whatsoever. No warranty, express or implied, is made as to the accuracy or completeness of any information provided within this channel. Viewing and using the “as-is" information of this channel is totally at your own risk. Always wear personal protection equipment and follow appropriate vehicle manufacturer service manual guidelines with original manufacturer parts only when performing any repairs, upgrades, or maintenance upon any vehicle.
