3200 Series Conveyors with Activated Roller Belt™ (ARB) Technology

The 3200 Series Conveyors with Intralox Activated Roller Belt™ (ARB) use innovative conveyance technology for merging, diverting and aligning of product.

Features and Benefits:

Flexibility to handle multiple product sizes without the need for changeover
Minimizes floor space consumption
Increased system reliability
Eliminates costly system controls, reducing complexity
Encased moving parts provide safer work environments
Low maintenance solution
Handles product as small as 6" x 6"

ARB Specifications:
2" pitch ARB Chain
Built on Dorner 3200 Series platform
Widths: 8" (203 mm) to 60" (1524 mm) in 2" (51 mm) increments
Lengths: Minimum 3 ft (914 mm)
Speeds: Up to 150 ft/min (46 m/min)
Optional powered transfer
ARB Solutions
90 degree transfers maintaining product orientation
Aligners / edge justification
Case turners
Bump turns
Touchless low friction merges
Rejects

Options & Accessories:
Standard support stands and guiding options are available
All standard 3200 Series mounting packages and gearmotors are available
