FreeCAD - Complete Beginner Tutorial : 3D Parametric Carport - Woodworking - Direct Assembly

In this video, I’ll show you how to model a fully parametric carport in FreeCAD.
We’ll build everything from a single master sketch, using simple extrusions and sub-object shape binder. No assembly workbench needed!

If you enjoy the video, don’t forget to leave a like, and consider subscribing to the channel.
And of course, if you have any questions, feel free to ask in the comments!

You can download the FreeCAD file, sketches, and macros (multiple clones, parts list) for FREE on my Ko-Fi page. If you’d like to support the channel, you can leave a small donation there. It really helps, thank you!
https://ko-fi.com/s/6115f13d62


You can follow me on social media to keep up with my projects and ideas:
X (Twitter) :   / deltahedra3d
Instagram :   / deltahedra
Ko-Fi : https://ko-fi.com/deltahedra

Chapters : Introduction 00:00
UI Tweaks : 00:47
Walkthrough : 01:31
MS Slab : 02:32
MS Back Post : 04:00
MS Front Post : 04:28
MS Rear Rafter : 04:59
MS Beam Lateral Section : 06:51
MS Back Batten : 07:29
MS Beam lateral Section Middle : 09:42
MS Back & Middle Braces : 11:07
MS Cross Beam : 13:13
MS Beam lateral section front : 14:24
MS Front Batten : 14:57
MS Front Rafter : 16:14
MS Front Brace : 17:17
Sub Shape Binder : 18:57
3D Back Post : 20:30
3D Front Post : 21:20
3D Back Rafter : 21:40
3D Cross Beams : 23:17
3D Front Rafter : 26:20
3D Braces : 27:13
3D Slab : 28:23
Varset : 28:37
3D Bolts Anchor : 30:00
Clones Macro & Part : 31:56
3D Lateral Beams : 34:14
3D Battens : 37:44
OSB Panels : 41:16
Conclusion : 43:05

#woodworking #cad #carpentry #freecad
