King Song N12 Pro Electric Scooter Overview

This video provides a comprehensive overview and tutorial of the King Song N12 Pro Scooter. The scooter boasts a powerful 1000w high torque motor, enabling quick acceleration and making it ideal for navigating city slopes with ease. It has a maximum speed of 50km/hr and can climb hills with a gradient of up to 47%. The scooter's 60V 858Wh 18650 high capacity lithium batteries provide a travel range of up to 80kms on a single charge.

The dual suspension system ensures a smooth and comfortable ride, while the innovative folding design allows for fast and easy folding. The scooter also features disc braking, drum braking, and regenerative anti-lock braking systems. A large and clear LED display shows the mode, speed, battery level, and distance. Additionally, the scooter comes with a new app that provides the best connectivity experience via Bluetooth. With the app, you can lock and unlock your scooter, change your settings such as speed, start, and brake settings, and monitor your ride data. The video gives step by step instructions on how to use the display and the advanced settings through the King Song App.

Overall, the King Song N12 Pro Scooter offers a powerful and versatile ride that is perfect for navigating city streets and tackling hills with ease.


Product Link: https://epiccycles.ca/product/electri...


Scooter Specs:


Model: KS-N12 PRO

Unfolding Size: 1275(L) *647(W)*1250(H) mm

Folding Size: 1275(L) *647(W)*625(H) mm

Packing Size: 1315(L)*315(W)*650(H) mm

MAX Loading: 120 KG

Rider Age

Accelerator: Push Throttle

Brakes: EABS + Front Drum brake + Rear disc Brake

Suspension: Front & Rear suspension

Tire Size: 10″ Honeycomb Tires or pneumatic tires

Max Speed: 50 KM/H (ECO: E – 20 KM/H; D – 30KM/H; S – 50KM/H)

Range: 80 KM

Gradeability: 25° (47%)

Deck width: 22 CM

Applicable Terrain:
Cement roads, asphalt roads, flat muddy road, steps not higher than 2cm, and trenches not exceeding 5cm

IP Level: IP54

Front LED: 2*1W + 1.5W

Frame Material: Aviation Aluminum Alloy

Net Weight: 27.5KG

Gross Weight: 31 KG

Rated Voltage (VDC): 60 V

Charge Voltage (VDC): 67.2 V

Battery Capacity: 14.5 Ah / 858 Wh

BMS Spec.
Temperature /Short Circuit /Low Voltage /Over Current /Over Charged Protection

Cycle life: 500 charge-discharge cycles greater than 75% of rated capacity

Storage Time: 12 Months

Battery Weight: 3.8 KG

scheme: FOC sine wave control

Operating Voltage: 48-67.2V

Current limit: 30 A

Motor Type: Brushless Hall DC Motor

Rated Power: 1000 W

Peak Power: 1400 W

Rated Power: 134.4 W

Input Voltage: AC 100 V-240 V

Out-put Voltage: 67.2 V

Out-put Current: 2 A

DC line interface model: Aviation plug, φ3*1.6 mm

Charging Time: 7-8 H

Motherboard: kingsong Self-developed controller system

Steering switch: Integrated switch combination of steering and electric horn

Bluetooth System:
Built-in 5.0 Bluetooth module, can be connected to the King Song APP to set vehicle parameters

Light system:
Built in 2*1W + External 1.5W high brightness light , separate tail light + separate turn signal light, and atmosphere light bars on the left and right sides of the scooter body.

Buzzer:
The whole scooter built in a buzzer for system operation indication and fault alarm.

Temperature Control System:
Real-time monitoring of motherboard and motor temperature.

Anti-theft alarm function

Sounds off loud audible alarm if anyone moves the scooter when locked on King Song APP
