2022 Freestyle FPV Drone Build - Configuration and Setup

Uncertain about what to buy? Check out THE ULTIMATE FPV SHOPPING LIST: https://www.fpvknowitall.com/ultimate...

SUPPORT ME ON PATREON at: http://bit.ly/2Ep5Sia

THIS IS MY FULL TIME JOB. Here are other ways that you can support me: https://www.fpvknowitall.com/support-me/

---

Get your FPV Drone DIY Kit at GetFPV:
Analog version - https://bit.ly/42R0qh1
DJI FPV HD version - https://bit.ly/3GWB6eV

You can also buy a pre-assembled ready-to-fly quadcopter:
Analog version - https://bit.ly/3aMRx1l
DJI FPV HD version - https://bit.ly/399nksW

Suggested parts, tools, and other accessories are linked on the GetFPV product page.

Thingiverse album of 3D prints for this frame:
https://www.thingiverse.com/thing:487...

All videos in this playlist are at:
   • 2022 Freestyle FPV Drone Build For Total B...

If you're not using ELRS, here are some other setup guides that might help you get your receiver working.

Crossfire and Tracer setup guide:    • TBS Tracer Crossfire complete setup guide ...

ImmersionRC Ghost setup guide:    • ImmersionRC Ghost Complete Setup Guide

-- TABLE OF CONTENTS --

00:00:00 - Let's get this build set up!
00:00:32 - Before we get started...
00:01:16 - Update firmware on the FC

Download and install Betaflight -    • Betaflight 4.3 Install, Flash, Setup Tab |...
Vifly Shortsaver -    • ViFly ShortSaver is the smoke stopper you ...

00:05:56 - Setup Motor protocol. Enable bidirectional DSHOT.
00:08:00 - Check motor order and direction
00:10:04 - Check board alignment
00:11:13 - DJI ONLY: Activate vTX, goggles, and controller
00:13:36 - DJI ONLY: Bind vtx, goggles, and controller
00:15:17 - Update ExpressLRS on Zorro controller

ExpressLRS full getting-started guide -    • ExpressLRS definitive getting started guide

00:18:50 - Download and install ELRS Lua Script
00:20:03 - Configure FC to talk to receiver
00:21:12 - Flash ELRS receiver
00:24:18 - Create new model in radio and set up endpoints
00:29:47 - Run ELRS Lua and configure ELRS
00:32:28 - Load Betaflight presets for our setup

My custom preset repo URL is: https://github.com/joshuabardwell/fir...
The Github Branch is: jb-presets

00:34:39 - NON-DJI ONLY: Set up Aux switches and Modes
00:40:27 - DJI ONLY: Controller setup, OSD, and aux modes
00:48:12 - ANALOG ONLY: Set up On-screen Display
00:53:23 - ANALOG ONLY: Set up video transmitter and vtxtable
00:57:24 - ANALOG ONLY: How to change channel using on-screen display
00:58:47 - This configuration is nearly done!!!
