Roland SoundCanvas SC-88 - Teardown and Repair
Автор: CookingComponents
Загружено: 2022-01-23
Просмотров: 5949
Описание:
Exhaustingly long teardown and repair of a Roland SoundCanvas SC-88.
======= Content =======
00:00 - Intro
01:34 - The problem
02:01 - Mistaken reset button
03:32 - Teardown
15:37 - First hint
17:01 - Further teardown
19:03 - Money shot
19:59 - Checking power rails
22:57 - Checking reset
30:27 - Checking crystals
34:14 - Desoldering the capacitors
42:03 - Found the leaky problem
43:33 - Broken trace
49:25 - Fixing the trace
59:52 - Replacing capacitors
01:03:03 - Testing - The magic moment ™
01:04:16 - Fixing the PCB
01:07:17 - Reverse teardown
01:24:26 - Powering up
01:29:24 - The real test - Is it a computer?
01:31:21 - Having fun!
