A SURPRISINGLY simple FEA method to determine BULK MODULUS

This video shows a surprisingly simple finite element based approach of determining the Bulk Modulus of a homogeneous block of Polypropylene. Here, the theory behind numerical model setup was explained, the model set and ran, and bulk modulus determined. To prove it works, I determined analytically the bulk modulus and this was found to agree with the numerically determined bulk modulus. This approach will be useful for analysis of bulk modulus of heterogeneous media like lattice and syntactic foam structures.

#bulkmodulus #fea #feamethod #3drve #determinebulkmodulus #poissonratio #homogeneousmaterial #heterogeneousmaterial#abaqustutorial #rvemodelling #rve #abaqusmodelsetup #representativevolumeelement #latticestructures #syntacticfoams

Time stamps
-------------------------------------------------------------------------------------------------------
00:00 - Intro
00:56 - Comment that led to making of this video
01:12 - How reliable is Bulk modulus determined numerically?
02:34 - Definition of bulk modulus
03:08 - Theory of modle setup for finding Bulk Modulus
04:57 - Model setup dimensions and properties
05:51 - ABAQUS Model Setup for determing bulk modulus
10:09 - ABAQUS Simulation Results
11:26 - Analysis of Simulation Results to Calculate Bulk Modulus
13:25 - Numerical determination of Bulk Modulus
14:57 - Outro

--------------------------------------
