Fusion 360 | Master Model Workflow
Автор: Fusion 360 School
Загружено: 2021-10-03
Просмотров: 22858
A master model (top down design) exercise.
Download the master model at the following public share link (generated within Fusion 360):
https://a360.co/3isfYCf
Check out a previous master model video:
• Fusion 360 - Master Model | Top Down Design
If you have found this video useful and would like to support me, you can buy me a coffee at
https://www.buymeacoffee.com/fusion36...
or you can also support me on Patreon at
https://www.patreon.com/fusion360scho...
Any contribution can go towards improving the quality of the channel. Thank you.
#fusion360school
#fusion360MasterModel
#fusion360TopDownDesign
0:00 Intro
0:56 What should we include in the master model?
3:46 Splitting into components
5:50 Detailing of ear cup
11:03 Detailing of N Frame
13:41 Creating recess in swivel
15:30 Creating pins on ear cup
16:38 Creating pin recess on N Frame
17:53 Adding joints
20:11 Implementing master model approach at a lower level
21:48 Making changes
