Drawing Mohr's Circle using the Stress-Transformation Equations
Автор: LearnMechE
Загружено: 2016-11-30
Просмотров: 734
Описание:
The stress transformation equations are graphed with theta on the horizontal axis and the stresses on the vertical axis. They are then graphed with tau on the vertical axis and sigma on the horizontal axis. When graphed this way, the equations result in a circle. This circle is known as Mohr's Circle, which allows a different geometric interpretation of the equations.
Made by faculty at the University of Colorado Boulder, College of Engineering & Applied Science.
Check out our Mechanics of Solids playlist: • Mechanics of Solids
Check out our website for screencasts organized by popular textbook: http://www.LearnMechE.com/screencasts...
