GT3071r Ball Bearing Turbo Rebuild 700382-5020

GT3071R Ball Bearing Turbo Rebuild by:Turbo Lab

Learn How to Rebuild Your Ball Bearing Turbo Charger. If you need Parts for Your Turbo Build we also Sell Everything to Build a New Cartridge.

Shopping: www.turbolabofamerica.com

Community: www.facebook.com/groups/turbolab/

Business page: www.facebook.com/turbolabamerica

Buy GT35R HX40 turbine: https://421b62.myshopify.com/products...

The original T67 GT37R Compressor Wheel has a 5 mm superback and needs to be machined down to 2.35mm to work on a ballbearing cartridge of you can buy our Compressor Wheel (I will leave a link here when I make the listing)

Gt37r hx40 hybrid v band: https://421b62.myshopify.com/products...

Gt37r hx40 hybrid t3 1.06 ar : https://421b62.myshopify.com/products...

Gt37r ball bearing rebuild kit : https://421b62.myshopify.com/products...

Gt37r turbine wheel shaft : https://421b62.myshopify.com/products...

Gt37r T67 billet wheel (not the same as all 6765 or 6766) http://turbolabofamerica.com/gt37r-pr...

Gen2 6262 6266 6466 6766 seal kit: https://421b62.myshopify.com/products...

6262 gen 1 billet wheel: https://421b62.myshopify.com/products...

6262 gen 2 billet wheel: https://421b62.myshopify.com/products...

6466 billet compressor wheel: https://421b62.myshopify.com/products...

6766 precision turbine 6.35mm shaft bore (works for ball bearing and journal bearing)
https://421b62.myshopify.com/products...

6262 turbine (works for ball bearing and journal bearing):
https://421b62.myshopify.com/products...

5858 5031 6031 6266 6262 6766 standard bore journal bearing rebuild kit:
https://421b62.myshopify.com/products...

Gt3071r gt3076r 9 blade turbine upgrade: https://421b62.myshopify.com/products...

Gt3071r gt3076r 10 blade replacement turbine: https://421b62.myshopify.com/products...

Gt2860r gtx2860r turbine: https://421b62.myshopify.com/products...

Gt2871r turbine: https://zh11v5v20gygh7rz-80204955928....

GTX35r billet wheel compressor housing and plate:
https://421b62.myshopify.com/products...

Gt35r GTX35r ball bearing brass retainer upgrade rebuild kit:
https://421b62.myshopify.com/products...

Gt2554r through gt3076r ball bearing brass retainer upgrade rebuild kit:
https://421b62.myshopify.com/products...

Contact: turbolabamerica@gmail.com

CHRA part number: 700177-5004

GT3071R Turbo part number: 700382-5020
Part Number: 700382-5020s
Model Number: GT3071R
Approx Horsepower Range for Engine Capacity: 300-460Hp (1.8L-3.0L)

CHRA(core): 700177-5004
Compressor Housing P/N: 467987-0015
Compressor Housing Air Ratio: 0.50
Compressor Wheel Size (mm): 53.14mm x 71mm
Compressor Wheel Trim: 56

Turbine Wheel Size (mm): 55mm x 60mm 10 blade
Turbine wheel Trim: N/A
Turbine Housing & Air Ratio Size: 0.64
Turbine Housing Inlet port: Single

Integral Wastegate: YES
Actuator Pressure (psi/kpa): N/A
Water Cooled Centre Housing: YES
Ball Bearing: YES
