Do it Yourself - Sparkplug and Air Filter Maintenance on a Kawasaki ZX 6R 636

Here you have an A-Z sparkplug and air filter change on a ZX-6R aka 636. Hope you enjoy. #motorcycle #kawasaki #suzuki #bmw #ktm #honda #harleydavidson #indian #ducati #bikelife #636 #zx6r #zx10r #oil #sparkplugs

0:00 - Introduction
0:12 - Sparkplugs Used
0:27 - Service Interval
0:54 - Tools Used
2:09 - Step 1: Remove most of the gas from the gas tank.
2:37 - Step 2: Remove the steering damper. If you don't have one remove the top 2 bolts that hold the tank to the frame.
3:33 - Step 3: Remove the seat and disconnect the battery.
3:58 - Step 4: Remove the farings below the tank.
4:35 - Step 5: Remove 2 rubber host fittings on the rear of the tank.
5:14 - Step 6: Disconnect servo buddy wire.
5:24 - Step 7: Remove tank hinge bolt.
5:43 - Step 8: Disconnect the fuel line under the tank.
6:05 - Step 9: Remove tank and place is on a towel or soft place.
6:10 - Step 10: Disconnect the two hoses on the back of the air filter.
6:24 - Step 11: Remove bolt at the top of the air filter.
6:30 - Step 12: Loosen the throttle body clamp bolts on each side of the airbox with 5-7 turns.
7:15 - Step 13: Take off air filter and clean it or replace it.
7:22 - Step 14: Lift off air box and disconnect the bottom air hose from the air box.
7:40 - Step 15: Make sure bottom of airbox throttle body clamp bolts are attached and loose ready for reinstallation.
7:58 - Step 16: Remove wires from all 4 coil packs.
8:11 - Step 17: For all 4 cylinders, remove coil pack, remove old sparkplug, insert new spark plug, and insert lubed coil pack.
9:30 - Step 18: Attach wires to all 4 coil packs.
9:38 - Step 19: Install Airbox - Will talk you through it.
13:04 - Step 20: Install gas Tank - Will talk you through it.
15:15 - Step 21: Install both farings that are under the tank.
16:16 - Step 22: Install the steering damper or if you don't have one, install the two bolts at the top of the tank.
18:01 - Step 23: Connect the battery cables and install the registration bag and seat.
18:53 - Step 24: Add the gas back in the tank and start her up.
