Installation of a Delta 800 Series including a Delta Dual V3, HLA and Battery Backup

The robust and reliable Delta Bespoke 800 Series – Dual V3
Packaged Pumping Station has been specifically
designed to collect ground and surface water from basements,
below ground structures.

The Delta Bespoke 800 Series of Package Pumping Station are
available in depths from 1250mm to 2000mm and with varying
pumping capabilities from the Delta Single V3 Foul to powerful
Delta Dual V6 pump.

Typical applications include (but are not limited to) Type C, Cavity
Drained Waterproofing solutions and/or surface water from roofs,
buried roofs, terraces and patios (subject to selection criteria).

Delta Bespoke 800 Series – Dual V3 (800.1750) system includes:
a polyethylene chamber, 1¼” PVC internal pipework, two Delta V3
sump pumps, 110mm inlet, 50mm cable duct, 110mm vent and 2”
discharge. This product is specifically designed for below ground
applications where hydrostatic water pressure may be present.

We recommend surrounding the Delta Bespoke 800 Series Dual V3 with concrete to prevent movement. An access cover is not supplied, as these are generally site specific and installed in the final finish. If required, the chamber will accept a standard 450mm x 600mm cover and frame. Inlets can easily be drilled and sealed on site, making this product straightforward to install.

Basement drainage systems are further enhanced with additional protection with high level water alarms, control panels and battery backups as a second line of defence.

A high-level water alarm will notify a building owner/occupier if the sump pump system has stopped working. Battery backups will maintain power supply to sump pumps in the event of a power outage

The Delta Bespoke 800 Series – Dual V3 (800.1750) is not
suitable for collecting foul water.

For more information visit www.deltamembranes.com/product-categories/basement-sumps-and-drainage/
