#34 - Tektronix TDS 540A oscilloscope repair
Автор: FeedbackLoop
Загружено: 2015-12-29
Просмотров: 54971
This scope suffered from the classic problem for this line: leaky electrolytic capacitors. All 96 capacitors were replaced, and a few broken PCB traces restored. A backup of Dallas DS1650Y NVRAM was made as well.
Schematics: http://hakanh.com/dl/kits.htm
Service manual: http://exodus.poly.edu/~kurt/manuals/...
Discussion: http://www.eevblog.com/forum/testgear...
Followup video: • #36 - Enabling FFT option in Tektronix TDS...
