Unlimited Cold Carbonated Soda on Tap DIY Kegerator!

edit Turns out even the stronger relief valve cannot handle the pressure when the pump is forcing the water into the tank. I moved back to using the valve I had rigged permanently sealed.

edit Regarding the carbonation stone lid from Keg Land: "For the Carbonator Keg Lid to work well, the mains water pressure should be 10-15 psi higher than your CO2 regulator" I like to have my soda carbonated at 100 PSI so I am not sure how carbonated the soda will be at such low PSI compared to say 100 PSI with the Big Mac carbonator. As far as the more basic setup of co2 to corny keg, I didn't want to have to wait at all or deal with swapping kegs or having a cold plate and managing the ice and refilling and dealing with the draining of that... Just no delay on demand carbonated soda, as much as I want until my co2 runs out then that's all I have to do is refill it and I'm set.

videos:

   • Setting up a Home On-Tap Carbonation Syste...
   • Everything I have learned about Unlimited ...
   • How to build a Kegerator from a Danby comp...

info:

https://www.multiplexbeverage.com/pro...
https://foxxequipment.com/search?q=12...
https://www.kegoutlet.com/oetiker-cla...
https://www.instructables.com/Chest-F...
https://www.instructables.com/Home-ca...
https://www.truetex.com/carbonation.htm
https://tasteofartisan.com/detailed-k...
https://tasteofartisan.com/how-to-mak...
https://www.chicompany.net/carbonator...

parts:

https://www.amazon.com/hz/wishlist/ls...
https://www.chicompany.net/carbonator...
https://www.totalapex.com/carbonators...
https://www.kegoutlet.com/kp110-itali... (high psi relief valve)

Apex parts:

Product Code Product Qty. Price Subtotal
3008 1/4 STEM FOR 3/8 NUT 1 $0.64 $0.64
3094 3/8 FEMALE FLARE CAP NUT 1 $2.42 $2.42
3178 3/8 NUT STAINLESS STEEL 1 $2.04 $2.04
170-04102-77 BEVLEX POLYESTER-REINFORCED POLYETHYLENE BEVERAGE HOSE .265" ID X .457" OD WHITE TRACER 100 FT 1 $26.45 $26.45
170-06100-77 BEVLEX POLYESTER-REINFORCED POLYETHYLENE BEVERAGE HOSE .380" ID X .635" OD WHITE TRACER 100 FT 1 $41.05 $41.05
16700010-100 CLAMP STEPLESS 13.3MM 20 $0.20 $4.00
16700016-100 CLAMP STEPLESS 15.7MM 20 $0.20 $4.00
NY45-4 FLARE GASKET 1/4 NYLON 20 $0.08 $1.60
NY45-6 FLARE GASKET 3/8 NYLON 20 $0.09 $1.80
63NY WASHER CO2 NYLON 10 $0.11 $1.10
111A100F11AA250 BRASS PUMP 100 GPH 250 PSI WITH STRAINER 1 $75.72 $75.72

ebay, facebook marketplace, craigslist, etc.

-Knipex 1099 Ear Clamp Pliers Front & Side Jaw Oetiker System Tool
-McCann’s big Mac 1/3 HP Soda / Water Carbonator 120V
-TAPRITE 3741 CO2 Regulator Primary Dual Gauge 160# 2000# psi ggs
-chip inside the float valve Q6025L6, killed mine, found on ebay
