[HID + Switchback Retrofit] 18 Subaru Forester Headlight

This video details a DIY retrofit of HID (High Intensity Discharge) lights into the Morimoto D2S projector installed into an OEM Headlight housing. It can serve as a resource for anyone looking to upgrade their vehicle, and a step-by-step manual for the 2014-2018 Subaru Forester modification / facelift. This guide also includes replacing the OEM Halo (C-Light) with the Diode Dynamics Switchback C-Light borrowed from the Subaru Legacy.

✅ Comprehensive Instructions in adding HID Projectors to vehicle
✅ Walkthrough of a DIY Switchback (C-light) / Halo retrofit
✅ Tips and tricks (8+ Years electrical and automotive experience)
✅ Complete wiring guide with customized diagrams and references
✅ Aftermarket and OEM part numbers, and parts identification
✅ Some great music, but I will let you be the judge!

Like what you see? It only gets better from here!

Nothing is safe from ManicMods!

Come join me on an epic adventure to mod the world! 😁


Timestamps:

0:00 Objective

2:01 Section 1: Preparation Notes

Section 2: Disassemble Headlights
3:12 Step 1: Remove Headlights
5:11 Step 2: Headlight Prep
7:19 Step 3: Headlight Harness Mod (Adjusted w/ step 26 Correction)

Section 3: Bake and Open Headlight
8:16 Step 1: Bake and Open
10:48 Step 2: Reflector Removal
11:52 Step 3: Fitting Morimoto D2S
16:32 Step 4: Reflector Re-Install

Section 4: Leveling
17:02 Step 1: Mounting Open Headlight
18:26 Step 2: Leveling

Section 5: SwitchBack Install
19:47 Step 1: Removing C-Light Defuser
21:31 Step 2: Switchback Install

Section 6: Bake and Seal Headlights
24:17 Step 1: Oven Prep
24:42 Step 2: New Butyl and Staging
27:09 Step 3: Baking
27:37 Step 3.5: A Shroud correction and reference

Section 7: Final Wiring
28:35 Reference 1: Modular Headlight Wiring
30:13 Reference 2: Under the Hood

34:15 Results
