Pyboard Radio - Updated Tayloe Detector
Автор: NA5Y
Загружено: 2020-09-11
Просмотров: 7034
Описание:
As I mentioned in the last video
• Pyboard (STM32F4) Radio
I wasn't very happy with the performance of the Tayloe detector board so I had some made from JLCPCB. I have 2 or 3 to give away, send me an email if you are interested and I'll see if I can send one out
The circuit and kicad files are here:
https://github.com/thaaraak/Tayloe-Mi...
Bill of Materials
https://github.com/thaaraak/Tayloe-Mi...
And the code is here:
https://github.com/thaaraak/PyboardRadio
Don't forget you can pick up the bandpass filter kits from qrp-labs at:
https://qrp-labs.com/bpfkit.html
