Inside a Massive PCB Factory – The Brain of Electronics Revealed

#pcb #pcbfactory #electronicsmanufacturing #howitsmade #industrialprocess

Step inside a massive printed circuit board (PCB) factory and uncover how the brain of modern electronics is manufactured at an industrial scale. This full-process factory tour reveals how PCBs are designed, layered, etched, drilled, and assembled using high-precision automated machinery.

Watch copper-clad boards pass through advanced imaging systems, chemical etching lines, CNC drilling machines, and quality inspection stations. From single-layer boards to complex multi-layer PCBs, every step is carefully controlled to ensure accuracy, durability, and electrical performance.

You’ll also see how factories maintain strict cleanliness standards, micron-level tolerances, and automated testing to meet the demands of consumer electronics, automotive systems, and industrial devices.

Inside a PCB Factory | How the Brain of Electronics Is Made
Inside a Massive PCB Factory – The Brain of Electronics Revealed
The Brain of Electronics | Inside a Massive PCB Factory

🔌 What You’ll See in This Video
• PCB layering and lamination
• Copper etching and circuit imaging
• High-speed drilling and routing
• Solder mask and surface finishing
• Inspection, testing, and packaging

Welcome to NextGen Process.
We explore how advanced factories manufacture the technology that powers the modern world.
