EEVblog 1667 - Reverse Engineering the Brymen BM2257 Multimeter LowZ Mode

Reverse Engineering the Brymen BM2257 Multimeter front end to understand what changes have been made from the BM235 in the Low Z mode. DaveCAD time. Also some testing of the LowZ mode and how it works.
